Japa- 305 Off Road - Firewood Processor

Japa 305 Firewood Processor For effortless, Fast and Safe Processing of Firewood, Mobile and Tow options

Description:

The range of JAPA 305 firewood processors is designed for those who require easy mobility and effortless operation from their machine. The 305 model comes with a hydraulically driven chainsaw, which operate reliably and silently. The saw chain only rotates when the log is being cut. The splitting of the log is by means of a hydraulic cylinder that is activated when the saw-handle is pressed down to its lower position.

The hydraulically driven, 2.3 meter long conveyor transfers the firewood further from the splitting knife. Irrespective of whether you choose a tractor-powered, electrically powered or combustion engine-powered JAPA 305 model as your firewood processor, your firewood-processing experience will always be smooth, efficient and safe.

NEW!

The Japa 305 range is very mobile with Yard Tow, Off Road , and Road Tow options.

Technical Specifications:

*"Off-Road" Spec.*	305 TRH	305 E	305 BE
Hydraulics
Volume of hydraulic oil (l)	n.a.	20	20
Flow of hydraulic pump (bar.)	n.a.	30	30
Saw Cutting
Hydraulic Chainsaw	Standard	Standard	Standard
13" bar	Standard	Standard	Standard
Chain 0.325"	Standard	Standard	Standard
Max diameter of log (cm)	30	30	30
Max length of log (cm)	45	45	45
Sawchain Lubrication Capacity (l)	2	2	2
Log Splitting
Splitting force	5.6 ton	5.6 ton	5.6 ton
Automatic High-speed valve	Standard	Standard	Standard
Splitting knife, 2/4	Standard	Standard	Standard
Splitting knife, 5 ways	Option	Option	Option
Adjustment of the splitting knife	Standard	Standard	Standard
Output Conveyor
Length 2.3 m (fixed)	2.3 m	2.3 m	2.3 m
Width of the conveyor belt (mm)	200	200	200
Conveyor Drive	Hydraulic	Hydraulic	Hydraulic
Dimensions
Height in transport position (mm)	2700	2700	2700
Width in transport position (mm)	2250	2250	2250
Depth (mm)	950	950	950
Weight (kg)	434	540	540
Power source
Tractor hydraulics Oil Flow	30 l.p.m	n.a.	n.a.
Electric motor, 4.0 kW 415V	n.a.	Standard	n.a.
Vanguard Petrol Engine	n.a.	n.a.	14 hp
	Off Road Tow	Off Road Tow	Off Road Tow

Rights for technical modifications reserved. Warranty 1 year.

Key Features:

The maximum diameter of a log to be split is 30 cm
The maximum splitting length is 45 cm
Electric motor 4 kW or Honda* combustion engine 13 hp
A 3,8 metre (folding) or 2,3 metre (fixed) hydraulic conveyor
Machine weight 434-540 kg

Brochure Download:

Japa_offroad_en_2013_w
(588.0 Kb)
