SPLITTA 400TM takes round logs up to 40cm diameter and converts them into split firewood or kindling at rates over 12 cubic metres of solid timber per hour automatically!
The Unique splitting blade in the form of an ‘X’ is pushed into the end grain of the log. The blade is then retracted and the log fed sideways by a controlled distance. The cycle is then repeated.
The machine can be adjusted from producing firewood to kindling in a matter of seconds and the size of firewood or kindling can be set to between 15 to 120 mm
Watch the video case study 'Moving into the Firewood Business with the Fuelwood Splitta 400' featuring Simon N'Jie Managing Director of Artemis Tree Services
Overall Dimensions:
Length (excl Chutes) 2286 mm
Length (incl Chutes) 3117 mm
Width 1795 mm
Height 545 mm
Weight (net) 1040 Kg
Power Supplies:
Electric Drive 415v 3 Phase 9.2 kW - 39 lpm
PTO driven Pump and Tank
Customer Hydraulic Supply - 45 lpm @ 190 Bar max
Split Force:
Maximum 150 kN
Cycle Time:
Minimum 3.0 secs
Timber Input:
Round logs
40 cm max diameter
10 cm min diameter
Length 20,25 or 33 cm
Timber Output:
Split Section size 20 to 120 mm
Firewood Output 12.0 solid m3/hr maximum
Kindling Output 2.7 solid m3/hr maximum
Option extras:
Out-feed Conveya™ Length:-4500mm
Conversion Kits Ring length:- 20 25 33cm
